TP67B+
23
CHAPTER 5: T-SERIES BIOS & SOFTWARE
5.1 T-S
ERIES UEFI BIOS
T-Series UEFI BIOS Features
Overclocking Navigator Engine (O.N.E.)
Self Recovery System (S.R.S)
Smart Fan Function
BIO-Flasher: Update UEFI BIOS file from USB Flash Drive
A. Overclocking Navigator Engine (O.N.E.)
O.N.E provides 4 systems allowing users to customize personal overclock
settings: Manual CPU System, Manual Memory System, Manual PWM
System, and Manual Voltage System.
BIOS SETUP UTILIT
Y
Notice: Please Clear CMOS if syst em no display
after overclocking
====Manual CPU system====
Start Page [P age - Main]
Fixed CPU Ratio [D isa bl ed]
CPU Base Clock(1/100 MHZ) 10 000
CPU Core Current Max(Amp) 105
Power Limit 1 Value (Watt) 95
Power Limit 2 Switch [E nab le d]
Power Limit 2 Value 11 8
Enhanced Intel SpeedStep Tech [E nab le d]
Turbo Mode [E nab le d]
1 Core Ratio Limit 31
2 Core Ratio Limit 30
3 Core Ratio Limit 30
4 Core Ratio Limit 29
CPU C1E [E nab le d]
CPU Ratio 28
Version x.xx.xxxx. Copyright© 201x, A me rican Megatrends, Inc.
You can set the entrance Page
when you enter UEFI BIOS
Setup
Main Advanced Chipset Boot Security O.N.E Save & Exit
Select Screen
Select Item
Select
Change Opt.
General Help
Optimized Defaults
Save & Reset
Exit
Enter
+/-
F1
F3
F4
ESC
Notice:
Not all types of Intel CPU perform above overclock setting ideally; the difference will be based on the
selected CPU model.
!! WARNING !!
For better system performance, the UEFI BIOS firmware is being
continuously updated. The UEFI BIOS information described below
in this manual is for your reference only and the actual UEFI BIOS
information and settings on board may be different from this
manual. For further information of setting up the UEFI BIOS,
p
lease refer to the UEFI BIOS Manual in the Setu
p
CD.
