Biostar TP67B+ Версия 6.2 [42/59] Appendix spec in other languages
![Biostar TP67B+ Версия 6.2 [42/59] Appendix spec in other languages](/views2/1709085/page42/bg2a.png)
Motherboard Manual
40
APPENDIX: SPEC IN OTHER LANGUAGES
G
ERMAN
Spezif ikationen
CPU
Socket 1155
Intel Core i7 / i5 / i3 / Pent ium / C eleron
Prozessoren
Unterstützt Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization Technology /
Hyp er Threading
Chipsatz
Intel P67
Super E/A
IT8728
Bietet die häufig verwend eten alten Sup er
E/A-Funktionen.
Low Pin Count-Schnittstelle
Umgebungskontrolle,
Hardware-Überwachung
Lüfterdrehzahl-Controller/-Überwachung
"Smart Guardian"-Funktion von ITE
Arbeitsspeich
er
DDR3 DIMM-Steckplätze x 4
Max. 16GB Arbeitsspeicher
Jeder DIMM unterstützt 512MB/
1GB/2GB/4GB DDR3.
Dual-Kanal DDR3 Speichermodul
Unterstützt DDR3 1066 / 1333
Unterstützt DDR3 1600(OC) / 1866(OC) / 2133(OC)
registrierte DIMMs. ECC DIMMs werden nicht
unterstützt.
SATA 2 & 3 Integrierter Serial ATA-Controller
Datentransferrate bis zu 3.0Gb/s / 6.0Gb/s.
Konform mit der SATA-Spezifikation Version 2.0 / 3.0
LAN Realtek RTL 8111E
10 / 100 / 1000 Mb/s Auto-Negotiation
Halb-/ Vollduplex-Funktion
HD
Audio-Unters
tützung
ALC892
Unterstützt High-Definition Audio
5.1-Kanal-Audioausgabe
USB3.0
NEC uPD720200 / Asmedia ASM1042 Datenübertragungsraten bis zu 600 MB / s
PCI-Steckplatz x2
PCI-E Gen2 x 16 @ x16 Steckplatz x1
PCI-E Gen2 x 16 @ x4 Steckplatz x1
Steckp lätze
PCI-E Gen2 x1-Steckplatz x1
