Spezif ikationen
SATA3-Anschluss x2 Jeder Anschluss unterstützt 1 SATA3-Laufwerk
SATA2-Anschluss x4 Jeder Anschluss unterstützt 1 SATA2-Laufwerk
Fronttafelanschluss x1 Unterstützt die Fronttafelfunktionen
Front-Audioanschluss x1 Unterstützt die Fronttafel-Audioanschlussfunktion
CPU-Lüfter-Sockel x1
CPU-Lüfterstromversorgungsanschluss (mit Smart
Fan-Funktion )
System-Lüfter-Sockel x2 System-Lüfter-Stromversorgungsanschluss
"CMOS löschen"-Sockel x1
USB2.0-Anschluss x2 Jeder Anschluss unterstützt 2
Fronttafel-USB2.0-Anschlüsse
Verbraucher-IR Anschluss x1
Serieller Anschluss x1
S/PDIF Ausgangsanschluss x1 Unterstützt die digitale Audioausgabefunktion
Stromanschluss (24-polig) x1
Onboard-Ans
chluss
Stromansch lus s (8-polig) x1
Rückseiten-E
/A
PS/2-Tastatur x1
PS/2-Maus x1
S/PDIF Heraus x1
LAN-Anschluss x1
USB2.0-Anschluss x4
USB3.0-Anschluss x2
Audioanschluss x3
USB3.0 Geräte (durch NEC uPD720200 / Asmedia
ASM1042) USB2.0/USB1.X Geräte (durch P67)
Platinengröße
220 mm (B) X 305 mm (L) ATX
OS-Unterstüt
zung
Windows XP / Vista / 7
Biostar behält s ich das Recht vor, ohne Ankündigung
die Unterstützung für ein Betriebssystem
hinzuzufügen oder zu entfernen.
