Motherboard Manual
24
B. Self Recovery System (S.R.S.)
This function can’t be seen under UEFI BIOS setup, and is always on whenever
the system starts up.
However, it can prevent system hang-up due to inappropriate overclock
actions.
When the system hangs up, S.R.S. will automatically log in the default UEFI
BIOS setting, and all overclock settings will be re-configured.
C. Smart Fan Function
Smart Fan Function is under “Smart Fan Control” in “Advanced Menu”.
This is a brilliant feature to control CPU/System Temperature vs. Fan speed.
When enabling Smart Fan function, Fan speed is controlled automatically by
CPU/System temperature.
This function will protect CPU/System from overheat problem and maintain the
system temperature at a safe level.
BIOS SETUP UTILIT
Y
> PCI Subsystem Settings
> ACPI Settings/WakeUp Event control
> CPU Configuration
> SATA Configuration
> USB Configuration
> Super IO Configuration
> H/W Monitor
> SMART FAN Control
Version x.xx.xxxx. Copyright© 201x, American Megatrends, Inc.
SMART FAN Control
Main Advanced
Chip set Boo t
Security O.N.E Save & Exit
Sele ct Screen
Sele ct Item
Sele ct
Chan ge Opt.
General Help
Optimized Defaults
Save & Reset
Exit
Ente r
+/-
F1
F3
F4
ESC
↓
NOTE
Overclock is an optional process, but not a “must-do” process; it is not
recommended for inexperienced users. Therefore, we will not be responsible
for any hardware damage which may be caused by overclocking. We also
would no t
g
uarantee an
y
overclockin
g
p
erformance.
