![Biostar TP67B+ Версия 6.2 Руководство пользователя онлайн [45/59] 546675](/views2/1709085/page45/bg2d.png)
TP67B+
43
SPEC
Connecteur SATA3 x2
Chaque connecteur prend en charge 1 périphérique
SATA3
Connecteur SATA2 x4
Chaque connecteur prend en charge 1 périphérique
SATA2
Connecteur du panneau avant x1 Prend en charge les équipements du panneau avant
Connecteur Aud io du panneau avant x1 Prend en charge la fonction aud io du pann eau avant
Embase de ventilateur UC x1
Alimentation électrique du ventilateur UC (avec
fonction de ventilateur intelligent)
Embase de ventilateur système x2 Alimentation électrique du ventilateur système
Embase d'effacement CMOS x1
Connecteur USB2.0 x2
Chaque connecteur prend en charge 2 ports USB2.0
de panneau avant
Connecteur de IR du consommateur x1
Port série x1
Connecteur de sortie S/PDIF x1
Prend en charge la fonction de sortie audio
numérique
Connecteur d'alimentat ion x1
(24 broches)
Connecteur
embarqué
Connecteur d'alimentat ion x1
(8 broches)
E/S du
panneau
arrière
Clavier PS/2 x1
Souris PS/2 x1
Sortie S/PDIF x1
Port LAN x1
Port USB2.0 x4
Port USB3.0 x2
Fiche audio x3
USB3.0 dispositifs (par NEC uPD720200 / Asmedia
ASM1042) USB2.0/USB1.X dispositifs (par P67)
Dimensions
de la carte
220 mm (l) X 305 mm (H) ATX
Support SE
Windows XP / Vista / 7
Biostar se réserve le droit d'ajouter ou de supprimer
le support de SE avec ou sans préavis
