TP67B+
45
SPECIFICA
Connettore SATA3 x2 Ciascun connettore supporta 1 unità SATA3
Connettore SATA2 x4 Ciascun connettore supporta 1 unità SATA2
Connettore pannello frontale x1 Supporta i servizi del panne llo frontale
Connettore audio frontale x1 Supporta la funzione audio pannello frontale
Collettore ventolina C PU x1
Alimentazione ventolina CPU (con funzione
Smart Fan)
Collettore ventolina sistema x2 Alimentazione ventolina d i sistema
Collettore cancellaz ione CMOS x1
Connettore USB2.0 x2
Ciascun connettore supporta 2 porte USB2.0
pannello frontale
Connettore IR del consumatore x1
Porta seriale x1
Connettore output S/PDIF x1 Supporta la funzione d’output audio digitale
Connettore alimentazione x1
(24 pin)
Connettori
su scheda
Connettore alimentazione x1
(8 pin)
I/O
pannello
posteriore
Tas tiera PS/2 x 1
Mouse PS/2 x1
S/PDIF Fuori x1
Porta LAN x1
Porta USB2.0 x4
Porta USB3.0 x2
Connettore audio x3
USB3.0 dispositivi (da NEC uPD720200 /
ASM1042) USB2.0/USB1.X dispositivi (da P67)
Dimension
i scheda
220 mm (larghezza) x 305 mm
(altezza)
ATX
Sistemi
operativi
supportati
Windows XP / Vista / 7
Biostar si riserva il diritto di aggiungere o
rimuovere il supporto di qualsiasi sistema
operativo senza preavviso.
