TP67B+
49
ESPECIFICAÇÕES
Conector SATA3 x2 Cada conector suporta 1 dispositivo SATA3
Conector SATA2 x4 Cada conector suporta 1 dispositivo SATA2
Conector do painel frontal x1 Para suporte de várias funções no painel frontal
Conector de áud io frontal x1 Suporta a função de áudio no painel frontal
Conector da ventoinha da CPU x1
Alimentação da ventoinha da CPU (com a função
Smart Fan)
Conector da ventoinha do sistema x2 Alimentação da ventoinha do sistema
Conector para limpeza do CMOS x1
Conector USB2.0 x2
Cada conector suporta 2 portas USB2.0 no painel
frontal
Conector de IR do consumidor x1
Porta série x1
Conector de saíd a S/PDIF x1 Suporta a saída de áud io d ig ital
Conector de alimentação x1
(24 pinos)
Conectores
na placa
Conector de alimentação x1
(8 p inos)
Entradas/S
aídas no
painel
traseiro
Tec lado PS /2 x 1
Rato PS/2 x1
Saída S/PDIF x1
Porta LAN x1
Porta USB2.0 x4
Porta USB3.0 x2
Tomada de áudio x3
USB3.0 dispositivos (por NEC uPD720200 / Asmedia
ASM1042) USB2.0/USB1.X dispositivos (por P67)
Tamanho
da placa
220 mm (L) X 305 mm (A) ATX
Sistemas
operativos
suportados
Windows XP / Vista / 7
A Biostar reserva-se o direito de adicionar ou
remover suporte para qualquer sistema operativo
com ou sem aviso prévio.
