TP67B+
51
SPEC
Złącze SATA3 x2 Każde złącze obs ługuje 1 urządzenie SATA3
Złącze SATA2 x4 Każde złącze obs ługuje 1 urządzenie SATA2
Złącze panela przedniego x1 Obsługa elementów panela przedniego
Przednie złącze audio x1 Obsługa funkcji audio na panelu przednim
Złącze główkowe wentylatora
procesora x1
Zasilanie wentylatora procesora (z funkcją Smart
Fan )
Złącze główkowe wentylatora
systemowego x2
Zasilanie wentylatora systemowego
Złącze główkowe kasowania CMOS x1
Złącze USB2.0 x2
Każde złącze obs ługuje 2 porty USB2.0 na panelu
przednim
Złącze Konsument IR x1
Port szeregowy x1
Złącze wyjścia S/PDIF x1 Obsługa funkcji cyfrowego wyjścia aud io
Złącze zasilania (24 pinowe) x1
Złącza
wbudowan e
Złącze zas ilania (8 pinowe) x1
Back Panel
I/O
Klawiatura PS/2 x1
Mysz PS /2 x1
wyjścia S/PDIF x1
Port LAN x1
Port USB2.0 x4
Port USB3.0 x2
Gniazdo audio x3
USB3.0 urządzeń (przez NEC uPD720200 / Asmedia
ASM1042) USB2.0/USB1.X urządzeń (przez P67)
Wymiary
płyty
220 mm (S) X 305 mm (W) ATX
Obsluga
systemu
operacyjne
go
Windows XP / Vista / 7
Biostar zastrzega sobie prawo dodawania lub
odwoływania obsług i dowo ln ego systemu
operacyjnego bez powiado mienia.
