H55 HD BIOS Manual
17
Onboard PCI/PCI-E Devices Configuration
BIOS SETUP UTILITY
Advanced
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Onboard PCI/PCI-E Devices Configuration
Onboard PCIE Giga LAN [Auto]
Onboard LAN Boot ROM [Disabled]
Onboard PATA IDE Controller [Auto]
Onboard LAN MAC ID :
Options
Auto
Enabled
Disabled
Onboard PCIE Giga LAN
This item allows you to control the onboard LAN.
Options: Auto (Default) / Enabled / Disabled
Onboard LAN Boot Rom
This item allows you to select the Onboard LAN Boot ROM.
Options: Disabled (Default) / Enabled
Onboard PATA IDE Controller
This item allows you to select PATA IDE Controller operate mode.
Options: Auto (Default) / Enabled / Disabled
Onboard LAN MAC ID
This item shows the LAN MAC ID.
