H55 HD BIOS Manual
36
Clock Gen Configuration
BIOS SETUP UTILITY
Performance
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Clock Gen Configuration
PCIE Clock By [Auto]
PCIE Frequency Setting [100]
CPU Clock delay [No delay]
PCH Clock delay [No delay]
Options
Auto
Manual
PCIE Clock By
This item allows you to determine how to set PCIE Clock, by auto or manual.
Options: Auto (Default) / Manual
PCIE Frequency Setting
This item allows you to select the PCIE clock control.
Options: 100 (Default) / Min=100; Max=150
CPU/PCH Clock delay
This item allows you to select CPU/PCH Clock delay.
Options: No delay (Default) / 50ps / 100ps / 150ps / 200ps / 250ps / 300ps / 350ps
/ 400ps / 450ps / 500ps
