H55 HD BIOS Manual
31
DVMT/FIXED Memory Size
DVMT stands for “ Dynamic Video Memory Technology”. This is an enhancement
of the unified memory architecture (UMA) concept. DVMT will set the optimum
amount of memory to be allocated for a balance between graphics and system
performance. DVMT dynamically respond to system requirements and applications
demands, by allocating the proper amount of display, texturing and buffer memory
after the operating system has booted.
Options: 256MB (Default) / 128MB / Maximum DVMT
PAVP Mode
GMCH Protected Audio Video Path (PAVP) BIOS support.
Options: Lite (Default) / Disabled / High
South Bridge Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
South Bridge Chipset Configuration
EHCI Controller#1 [Enabled]
EHCI Controller#2 [Enabled]
HDA Controller [Enabled]
Internal HDMI Audio Codec [Enabled]
SMBUS Controller [Enabled]
SLP_S4# Min. Assertion Width [1 to 2 seconds]
USB Function [Enabled]
Enable/Disable USB
controller in system.
USB Function
This item allows you to activate USB function.
Options: Enabled (Default) / Disabled
EHCI Controller#1/2
This item allows you toenable integrated USB 2.0 RMH#1/2.
Options: Enabled (Default) / Disabled
