H55 HD BIOS Manual
8
2 Advanced Menu
The Advanced Menu allows you to configure the settings of CPU, Super I/O, Power
Management, and other system devices.
Notice
z Beware of that setting inappropriate values in items of this menu may cause
system to malfunction.
BIOS SETUP UTILITY
Main Advanced
PCIPnP Boot
Chipset Performance
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Configure CPU.Advanced Settings
WARNING: Setting wrong values in below sections
may cause system to malfunction.
> SuperIO Configuration
> Hardware Health Configuration
> Smart Fan Configuration
> ACPI Configuration
> Onboard PCI/PCI-E Devices Configuration
> Intel VT-d Configuration
> MPS Configuration
> PCI Express Configuration
> Smbios Configuration
> USB Configuration
> CPU Configuration
Exit
CPU Configuration
This item shows the CPU information that the BIOS automatically detects.
BIOS SETUP UTILITY
Advanced
vxx.xx (C)Copyright 198 5-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
This should be e nabled
in order to enab le or
disable the “Enh anced
Halt State”.
Configure advanced CPU settings
Module Version:01. 04
Manufacturer:Intel CPU
Frequency :
BCLK Speed :
Cache L1 :
Cache L2 :
Ratio Status:
Ratio Actual Value :
Cache L3 :
CIE Support [Enabled]
Hardware Prefetche r [Enabled]
Adjacent Cache Lin e Prefetch [Enabled]
Max CPUID Value Li mit [Disabled]
Execute-Disable Bi t Capability[Enabled]
Intel(R) Virtualiz ation Tech [Enabled]
CPU TM function [Enabled]
