H55 HD BIOS Manual
33
6 Performance Menu
This submenu allows you to change voltage and clock of various devices.
(However, we suggest you to use the default setting. Changing the voltage and clock
improperly may damage the device.)
Notice
z Beware of that setting inappropriate values in items of this menu may cause
system to malfunction.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset Performance
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Advance Performance Settings
WARNING:Please Clear CMOS if system no display
after overclocking.
CPU Frequency Setting [133]
DRAM Frequency [Auto]
> DRAM Timing Configuration
> Clock Gen Configuration
> Voltage Control
> Intel PPM Configuration
Intel GPU Clock [Auto]
Current CPU Frequency :
Current Memory Frequency :
SPEC/Current GPU Clock :
[ x23.0]CPU Ratio Setting
Intel(R)SpeedStep(tm)tech [Enabled]
Exit
Disable: Disable Gv3
Enable: Enable GV3
Intel(R) SpeedStep(tm) Tech
This item allows you to enable SpeedStep technology for better power saving.
SpeedStep is a technology built into some Intel processors that allows the clock
speed o f the processor to be dynamically changed by software.
Options: Enabled (Default) / Disabled
CPU Ratio Setting
This item allows you to set the CPU ratio frequency. This item is adjustable only
when SpeedStep Tech is set to Disabled.
Options: x23.0 (Default) / x9.0 ~ x22.0
CPU Frequency Setting
This item allows you to select the CPU Frequency.
Options: Min= 100MHz; Max= 800MHz
