TP45E XE BIOS M anual
17
Config Onboard PCI/PCI-E Devices
BIOS SETUP UTILITY
Advanced
vxx.xx (C)Copyright 1985-200x, Amer ican Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Onboard PCI/PCI-E Devices Conf iguration
Onboard PCIE VIA6330 Cntlr [Auto]
Onboard PCIE Giga LAN [Auto]
Onboard LAN Boot ROM [Disabled]
MAC ID Information
Options
Auto
Enabled
Disabled
Onboard PCIE VIA6330 Cntlr
This item allows you to control the onboard IDE/1394 controller.
Options: Auto (Default) / Enabled / Disabled
Onboard PCIE Giga LAN
This item allows you to control the onboard LAN.
Options: Auto (Default) / Enabled / Disabled
Onboard LAN Boot Rom
This item allows you to select the Onboard LAN Boot ROM.
Options: Disabled (Default) / Enabled
MAC ID Information
This item shows the LAN MAC ID.
