TP45E XE BIOS M anual
30
Manual Overclock System (M.O.S.)
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset O.N.E
vxx.xx (C)Copyright 1985-200x, Amer ican Megatre nds, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Over-Clocking Navigator settin g
WARNING: Setting wrong values in below sec tions
may cause system to m alfunction.
=========== Automate OverClock System ==== =======
============ Manual OverClock System ===== =======
Over-Clocking Navigator [Manual Ove rClock]
Intel(R) SpeedStep(tm) tech [Enabled]
Ratio CMOS Setting [ x8.0]
CPU Frequency Setting [200]
Over Clock Retry Count [3]
FSB(Bsel) To NorthBridge Latch [Auto]
DRAM Frequency [Auto]
Enhanced Mode [Auto]
> DRAM Timing Configuration
> Clock Gen Configuration
> Voltage Configuration
Memory Test [Disabled]
Auto OverClock System [V6-Tech En gine]
Exit
Options
Normal
Automate OverClock
Manual OverClock
MOS is designed for experienced overclock users.
It allows users to customize personal overclock setting.
Intel(R) SpeedStep(tm) Tech
This item allows you to enable SpeedStep technology for better power saving.
SpeedStep is a technology built into some Intel processors that allows the clock
speed of the processor to be dynamically changed by software.
Options: Enabled (Default) / Disabled
Ratio CMOS Setting
This item allows you to set the CPU ratio frequency.
Options: x6.0 / x7.0 / x8.0
CPU Frequency Setting
This item allows you to select the CPU Frequency.
Options: Min= 100 MHz; Max= 800 MHz
Over Clock Retry Count
This item allows you to set the overclock fail retry times.
Options: 3 (Default) / Min= 1; Max= 8
