TP45E XE BIOS M anual
4
IDE/SATA Configuration
The BIOS will automatically detect the presence of IDE/SATA devices. There is a
sub-menu fo r each IDE/SATA device. Select a device and press <Enter> to enter
the sub-menu of detailed options.
BIOS SETUP UTILITY
Main
vxx.xx (C)Copyright 1985-200x, Amer ican Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
IDE/SATA Confuguration
> SATA 1 Device
> SATA 2 Device
> SATA 3 Device
> SATA 4 Device
> SATA 5 Device
> SATA 6 Device
> Primary IDE Master
> Primary IDE Slave
Hard Disk Write Protect [ Disabled]
IDE Detect Time Out (Sec) [ 35]
Configure SATA#1 as [ IDE]
Max Ports on SATA#1 [ 6 Ports]
SATA#2 Configuration [ Enhanced]
SATA#1 Configuration [ Compatible]
> AHCI Configuration
Options
Disabled
Compatible
Enhanced
SATA#1 Configuration
This item allows you to control the onboard SATA controller.
Options: Compatible (Default) / Disabled / Enhanced
Configure SATA#1 as
This item allows you to choose the SATA operation mode.
Options: IDE (Default) / AHCI
Max Ports on SATA#1
This item appears only when SATA mode is set to AHCI/RAID.
Options: 6 Ports (Default) / 4 Ports
SATA#2 Configuration
This item allows you to control the onboard SATA controller.
Options: Enhanced (Default) / Disabled
