TP45E XE BIOS M anual
5
AHCI Configuration
BIOS SETU P U TILITY
Main
vxx .xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
AHCI Settings
AHCI CD\DVD Bo ot Time out [35]
> AHCI Port0
> AHCI Port1
> AHCI Port2
> AHCI Port3
> AHCI Port4
> AHCI Port5
AHCI BIOS Supp ort [Ena bled]
Enables for supporting
AHCI BIOS Support
This BIOS feature controls the AHCI function of the SATA controller.
Options: Enabled (Default) / Diabled
AHCI CD/DVD Boot Time Out
This BIOS feature allows you to set the AHCI CD/DVD boot time out.
Options: 35 (Default) / 0 / 5 / 10 / 15 / 20 / 25 / 30
AHCI Port0/Port1/Port2/Port3/Port4/Port5
BIOS SETUP UTILITY
Main
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
AHCI Port0
S.M.A.R.T. [Enabled]
Device :
SATA Port0 [Auto]
Select the type
of device connected
to the system.
