TP45E XE BIOS M anual
8
2 Advanced Menu
The Advanced Menu allows you to configure the settings of CPU, Super I/O, Power
Management, and other system devices.
Notice
z Beware of that setting inappropriate values in items of this menu may cause
system to malfunction.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset O.N.E
vxx.xx (C)Copyright 1985-200x, Amer ican Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Configure CPU.Advanced Settings
WARNING: Setting wrong values in below sections
may cause system to m alfunction.
> USB Configuration
> Config Onboard PCI/PCI-E Dev ices
> SuperIO Configuration
> Hardware Health Configuratio n
> Smart Fan Configuration
> PM/ACPI Configuration
> CPU Configuration
Exit
CPU Configuration
This item shows the CPU information that the BIOS automatically detects.
BIOS SETUP UTILITY
Advanced
vxx.xx (C)Copyright 1985-200x, American Megatre nds, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
This should be enabled
in order to enable or
disable the “Enhanced
Halt State”.
Configure advanced CPU settings
Module Version:3F.09
Manufacturer:Intel
Frequency :
FSB Speed :
Cache L1 :
Cache L2 :
Ratio Status:
Ratio Actual Value:
Intel(R) C-STATE Tech [Enabled]
C1E Support [Enabled]
Hardware Prefetcher [Enabled]
Max CPUID Value Limit [Disabled]
CPU TM function
Execute-Disable Bit Capability[Disabled]
Core Multi-Processing [Enabled]
[Enabled]
