TA960 BIOS Manual
24
FB Location
This item allows you to set the FB-DIMM location.
Options: Above 4G (Default) / Under 4G
PCI Express Configuration
BIOS SETUP UTILIT
Y
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Update
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
PCI Express Configuration
> Port #02 Features
> NB-SB Port Features
GPP Slots Power Limit, W [25 ]
GPP Slots Power Limit, W
Options: 25 (Default) / 0-255
Port #02 Features
BIOS SETUP UTILIT
Y
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Gen2 High Speed Mode [Disabled]
Link ASPM [Disabled]
Link Width [Auto]
Slot Power Limit,W [75 ]
Auto - RC only
advertize Gen2
capability.
Gen2 High Speed Mode
Options: Auto (Default) / Disabled / Software Initiated / Advertised RC
