TA960 BIOS Manual
27
6 Performance Menu
This submenu allows you to change voltage and clock of various devices.
(However, we suggest you use the default setting. Changing the voltage and
clock improperly may damage the device.)
Notice
z Beware of that setting inappropriate values in items of this menu may cause
system to malfunction.
BIOS SETUP UTILITY
Main Advanced
PCIPnP Boot
Chipset Performance
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Exit
Performance Settings
WARNING: Please Clear CMOS if system no display
after overclocking.
> Clock Control
> DRAM Timing Configuration
> Memory Configuration
> Voltage Configuration
> CPU Tuning
CPU Tuning
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
CPU Tuning
Hyper Transfer Link Configuration
CPU/HT Reference Clock (MHZ) [200]
Custom P-States [Disabled]
Link Speed : [Auto]
Link Width : [Auto]
Advanced Clock Calibration
Core Leveling [Auto]
[Disabled]
Performance
Allows BIOS to Select
CPU Over Clock.
CPU/HT Reference range
200MHz - 600MHz
