TA960 BIOS Manual
25
Link ASPM
Options: Disabled (Default) / L0s / L1 / L0x & L1
Link Width
Options: Auto (Default) / x1 / x2 / x4 / x8 / x16
Slot Power Limit, W
Options: 75 (Default) / 0-255
NB-SB Port Features
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
NP NB-SB VC1 Traffic Support [Disabled]
Link Width [Auto]
NB-SB Link ASPM [Disabled]
Options
Disabled
L1
NB-SB Link ASPM
Options: Disabled (Default) / L1
NP NB-SB VC1 Traffic Support
Options: Disabled (Default) / Enabled
Link Width
Options: Auto (Default) / x1 / x2 / x4
Primary Video Controller
Options: GFX0-GPP-IGFX-PCI (Default) / GPP-GFX0-IGFX-PCI /
PCI -GFX0-GPP-IGFX/ IGFX-GFX0-GPP-PCI
NB Power Management Features
This option controls the NB power management function.
Options: Auto (Default) / Disabled
