Motherboard Manual
34
FRENCH
SPEC
UC
Socket FM1
Processeurs AMD A-Series / E2-Series
L'architecture AMD 64 permet le calcul 32 et 64 bits
Chipset
AMD A55
Super E/S
ITE 8728
Fournit la fonctionnalité de Super E/S
patrimoniales la plus utilisée.
Interface à faib le co mpte de b roches
Initiatives de contrôle environnementales,
Moniteur d e mat ériel
Contrôleur de vitesse de ventilateur
Fonction "Gardien intelligent" de l'ITE
Mémoire
principale
Fentes DDR3 DIMM x 2
Capacité mémo ire max imale de 16Go
Chaque DIMM prend en charg e des DDR3
de 512Mo/1Go /2Go/4Go/8Go
Modu le d e mémo ire DDR3 à mod e à doub le vo ie
Prend en charge la DDR3 800/1066/1333/1600/1866
Prend en charge la DDR3 2000 (OC)
Les DIMM à registres et DIMM avec code correcteurs
d'erreurs ne sont pas prises en charge
SATA II
Contrôleur Serial ATA
int égr é
Taux de transfert jusqu'à 3 Go/s.
Conforme à la spécif icat ion SATA Vers ion 2.0
Prise en charge RAID 0,1,10
LAN
RTL8111E / RTL8111F
10 / 100 / 1000 Mb/s négociation automatique
Half / Full duplex capability
Codec audio
VT1708B/ ALC662
Sortie audio à 5.1 vo ies
Prise en charge de l'audio haute définit ion
Fente PCI Express Gen2 x16 x1
Fente PCI Express Gen2 x1 x2
Fentes
Fente PCI x3
Connecteur SATA x6
Chaque connecteur prend en charge 1 périphérique
SATA
Connecteur du panneau avant x1 Prend en charge les équipements du panneau avant
Connecteur Audio du panneau avant x1 Prend en charge la fonction audio du panneau avant
Connecteur de sortie S/PDIF x1 Prend en charge la fonction de sortie audio numérique
Embase de ventilateur UC x1
Alimentation électrique du ventilateur UC (avec fonction
de ventilateur intelligent)
Connecteur
embarqué
Embase de ventilateur système x1 Alimentation électrique du ventilateur système
