Motherboard Manual
40
PORTUGUESE
ESPECIFICAÇÕES
CPU
Socket FM1
Processadores AMD A-Series / E2-Series
A arquitectura AMD 64 p ermite uma co mputação de 32
e 64 bits
Chipset
AMD A55
Especificaçã
o Super I/O
ITE 8728
Proporciona as funcionalidades mais
utilizadas em termos da especificação
Super I/O.
Interface LPC (Low Pin Count).
In iciat ivas par a contro lo do amb iente
Monitorização do hardware
Controlador da velocidade da ventoinha
Função "Smart Gu ardian" d a ITE
Memória
principal
Ranhuras DIMM DDR3 x 2
Capacidad e máx ima de memória: 16GB
Cada módulo DIMM suporta uma
memória DDR3 de 512MB/
1GB/2GB/4GB/8GB
Módulo de memória DDR3 de canal duplo
Suporta módulos DDR3 800/1066/1333/1600/1866
Suporta módulos DDR3 2000 (OC)
Os módulos DIMM registados e os DIMM ECC não são
suportados
SATA II
Controlador Serial ATA integrado
Velocidades de transmissão de dados até 3 Gb/s.
Compat ibilidad e co m a especificação SATA versão 2.0
Suporta as funções RAID 0,1,10
LAN
RTL8111E / RTL8111F
Auto negociação de 10 / 100 / 1000 Mb/s
Capacidade semi/full-duplex
Codec de
som
VT1708B/ ALC662
Saída de áudio de 5.1 canais
Suporta a especificação High-Definition Audio
Ranhura PCI Express Gen2 x16 x1
Ranhura PCI Express Gen2 x1 x2
Ranhuras
Ranhura PCI x3
Conector SATA x6 Cada conector suporta 1 dispositivo SATA
Conector do painel frontal x1 Para suporte de várias funções no painel frontal
Conector de áud io frontal x1 Suporta a função de áud io no painel frontal
Conector de saída S/PDIF x1 Suporta a saída de áud io digital
Conector da ventoinha da CPU x1
Alimentação da vento inh a da CPU (com a função S mart
Fan )
Conectores
na placa
Conector da ventoinha do sistema x1 Alimentação da ventoinha do sistema
