Motherboard Manual
42
POLISH
SPEC
Procesor
Socket FM1
AMD A-Series / E2-Series Procesory
Architektura AMD 64 umożliwia przetwarzanie 32 i 64
bitowe
Chipset
AMD A55
Pamięć
główna
Gniazda DDR3 DIMM x 2
Maks. wielkość pamięci 16GB
Każde gniazdo DIMM obsługuje moduły
512MB/1GB/2GB/4GB/8GB DDR3
Modu ł pamięci DDR3 z trybem podwójnego kanału
Obsługa DDR3 800/1066/1333/1600/1866
Obsługa DDR3 2000 (OC)
Brak obsługi R egistered DIMM oraz ECC D IMM
Super I/O
ITE 8728
Zapewnia najbardziej powszechne funkcje
Super I/O.
Interfejs Low Pin Count
Funkcje kontroli warunków pracy,
Mon itor H/W
Kontroler prędkości wentylatora
Funkcja ITE "Smart Guardian"
SATA II
Zintegrowany kontroler Serial ATA
Transfer danych do 3 Gb/s.
Zgodność ze specyfikacją SATA w wersj i 2.0
Obsługa RAID 0,1,10
LAN
RTL8111E / RTL8111F
10 / 100 / 1000 Mb/s z automatyczną negocjacją
szybkości
Działanie w tryb ie połowicznego/pełnego dupleksu
Kodek
dźwiękowy
VT1708B/ ALC662
5.1 kanałowe wyjście audio
Obsługa High-Def in ition Aud io
Gniazdo PCI Express Gen2 x16 x1
Gniazdo PCI Express Gen2 x1 x2
Gniazda
Gniazdo PCI x3
Złącze SATA x6 Każde złącze obs ługuje 1 urządzenie SATA
Złącze panela przedniego x1 Obsługa elementów panela przedniego
Przednie złącze audio x1 Obsługa funkcji audio na panelu przednim
Złącze wyjścia S/PDIF x1 Obsługa funkcji cyfrowego wyjścia aud io
Złącze g łówkowe wentylatora
procesora x1
Zasilanie wentylatora procesora (z funkcją Smart Fan)
Złącza
wbudowane
Złącze g łówkowe wentylatora
systemowego x1
Zasilanie wentylatora systemowego
Содержание
- A57a setup manual 1
- Duplication of this publication in part or in whole is not allowed without first obtaining the vendor s approval in writing 1
- Fcc information and copyright 1
- The content of this user s manual is subject to be changed without notice and we will not be responsible for any mistakes found in this user s manual all the brand and product names are trademarks of their respective companies 1
- The vendor makes no representations or warranties with respect to the contents here and specially disclaims any implied warranties of merchantability or fitness for any purpose further the vendor reserves the right to revise this publication and to make changes to the contents here without obligation to notify any party beforehand 1
- This equipment has been tested and found to comply with the limits of a class b digital device pursuant to part 15 of the fcc rules these limits are designed to provide reasonable protection against harmful interference in a residential installation this equipment generates uses and can radiate radio frequency energy and if not installed and used in accordance with the instructions may cause harmful interference to radio communications there is no guarantee that interference will not occur in a particular installation 1
- Table of contents 2
- Ackage 3
- Chapter 1 introduction 3
- Hecklist 3
- Eatures 4
- Motherboard manual 4
- Otherboard 4
- Onnectors 5
- Motherboard manual 6
- Note represents the 1 6
- Otherboard 6
- Super i o 6
- Chapter 2 hardware installation 7
- Entral 7
- Nstalling 7
- Rocessing 7
- Cpu_fan1 cpu fan header 9
- Eaders 9
- Sys_fan1 system fan header 9
- These fan headers support cooling fans built in the computer the fan cable and connector may be different according to the fan manufacturer connect the fan cable to the connector while matching the black wire to pin 1 9
- A ddr3 modules 10
- Nstalling 10
- B memory capacity 11
- C dual channel memory installation 11
- D ddr speed support 11
- O means memory installed x means memory not installed the dram bus width of the memory module must be the same x8 or x16 11
- Atxpwr2 atx power source connector 12
- Motherboard manual 12
- Onnectors and 12
- Sata1 sata6 serial ata connectors 12
- The motherboard has a pci to sata controller with 6 channels sata interface it satisfies the sata 2 spec and with transfer rate of 3 gb s 12
- This connector provides 12v to cpu power circuit 12
- Atxpwr1 atx power source connector 13
- Before you power on the system please make sure that both atxpwr1 and atxpwr2 connectors have been plugged in 13
- Pci1 pci2 pci3 peripheral component interconnect slots 13
- This connector allows user to connect 24 pin power connector on the atx power supply 13
- This motherboard is equipped with 3 standard pci slots pci stands for peripheral component interconnect and it is a bus standard for expansion cards this pci slot is designated as 32 bits 13
- Motherboard manual 14
- Pex16_1 pci express gen2 x16 slot 14
- Pex1_1 pex1_2 pci express gen2 x1 slots 14
- Chapter 3 headers jumpers setup 15
- Ettings 15
- Panel1 front panel header 15
- Pin opened pin opened pin closed pin1 2 closed 15
- The illustration shows how to set up jumpers when the jumper cap is placed on pins the jumper is close if not that means the jumper is open 15
- This 16 pin connector includes power on reset hdd led power led and speaker connection it allows user to connect the pc case s front panel switch functions 15
- Umpers 15
- Clear cmos procedures 16
- F_ usb2 usb1 f_ 16
- F_usb1 f_usb2 headers for usb 2 ports at front panel 16
- Jcmos1 clear cmos header 16
- Motherboard manual 16
- Placing the jumper on pin2 3 allows user to restore the bios safe setting and the cmos data please carefully follow the procedures to avoid damaging the motherboard 16
- Remove ac power line 2 set the jumper to pin 2 3 close 3 wait for five seconds 4 set the jumper to pin 1 2 close 5 power on the ac 6 load optimal defaults and save settings in cmos 16
- These headers allow user to connect additional usb cable on the pc front panel and also can be connected with internal usb devices like usb card reader 16
- F_audio1 front panel audio header 17
- Jspdifout1 digital audio out connector 17
- Note it is recommended that you connect a high definition front panel audio module to this connector to avail of the motherboard s high definition audio capability 17
- This connector allows user to connect the pci bracket spdif output header 17
- This header allows user to connect the front audio output cable with the pc front panel this header supports hd and ac 97 audio front panel connector 17
- J_print1 printer port connector 18
- Motherboard manual 18
- This header allows you to connector printer on the pc 18
- Chapter 4 raid functions 19
- Features and benefits 19
- Perating 19
- Raid 0 19
- Features and benefits 20
- Motherboard manual 20
- Raid 1 20
- Features and benefits 21
- Raid 10 21
- A driver installation 22
- B software installation 22
- C manual 22
- Chapter 5 useful help 22
- Nstallation 22
- Ehot line optional 23
- Installing software 23
- Launching software 23
- Oftware 23
- Bios update utility 25
- Cpu overheated 25
- Nformation 25
- Ami bios 26
- Boot block beep codes 26
- Motherboard manual 26
- Post bios beep codes 26
- Troubleshooting post bios beep codes 26
- Roubleshooting 27
- Chapter 6 bios update 28
- Download the proper bios from www biostar com tw 28
- Installing bios update utility from the cd driver 28
- Motherboard manual 28
- There are three ways to update the bios bios update utility bios online update utility and biostar bios flasher 28
- Tility 28
- In the system and click save 29
- Installing bios update utility from the cd driver 30
- Motherboard manual 30
- Please make sure the system is connected to the internet before using this function 30
- Tility 30
- Biostar bios 32
- Lasher 32
- Motherboard manual 32
- Appendix spec in other languages 34
- Motherboard manual 34
- Motherboard manual 36
- Motherboard manual 38
- Talian 38
- Motherboard manual 40
- Panish 40
- Motherboard manual 42
- Ortuguese 42
- Motherboard manual 44
- Motherboard manual 46
- Ussian 46
- Low pin count interface 48
- Motherboard manual 48
- جﺮﺥ ﺬﻔﻨﻡ s pdif دﺪﻋ1 48
- ﺔﺤﺘﻓ ddr3 dimm دﺪﻋ2 48
- ﺔﺤﺘﻓ gen2 x16 pci express دﺪﻋ1 48
- ﺔﺤﺘﻓ pci express gen2 x1 دﺪﻋ2 48
- ﺔﺤﺘﻓ pci دﺪﻋ3 48
- ﺔﻴﻡﺎﻡﻷا ﺔﺣﻮﻠﻟا ﺬﻔﻨﻡ دﺪﻋ1 48
- ﺬﻔﻨﻡ sata دﺪﻋ6 48
- ﻲﻡﺎﻡﻷا تﻮﺼﻟا ﺬﻔﻨﻡ دﺪﻋ1 48
- Apanese 50
- Motherboard manual 50
