Motherboard Manual
38
SPANISH
Especificación
CPU
Conector FM1
Procesadores AMD A-Series / E2-Series
La arquitectura AMD 64 permite el procesado de 32 y
64 bits
Conjunto de
chips
AMD A55
Súper E/S
ITE 8728
Le ofrece las funcionalidades heredadas de
uso más común Súper E /S.
Interfaz de cuenta Low Pin
In ic iat ivas de control d e entorno,
Monitor hardware
Controlador de velocidad de ventilador
Función "Guardia inteligente" de ITE
Memoria
principal
Ranuras DIMM DDR3 x 2
Capacidad máxima de memoria de 16GB
Cada DIMM admite DDR de
512MB/1GB/2GB/4GB/8GB
Módulo de memoria DDR3 de canal Doble
Admite DDR3 de 800/1066/1333/1600/1866
Admite DDR3 de 2000 (OC)
No admite DIMM registrados o DIMM compatibles con
ECC
SATA II
Controlador ATA Serie Integrado
Tasas de transferencia de hasta 3 Gb/s.
Compat ib le con la versión SATA 2.0
Admite RAID 0,1,10
Red Local
RTL8111E / RTL8111F
Negociación de 10 / 100 / 1000 Mb/s
Funciones Half / Full dúplex
Códecs de
sonido
VT1708B/ ALC662
Salida de sonido de 5.1 canales
Soporte de sonido de Alta Definición
Ranura PCI Express Gen2 x16 X1
Ranura PCI express Gen2 x1 X2
Ranuras
Ranura PCI X3
Conector SATA X6 Cada conector soporta 1 dispositivos SATA
Conector de p ane l frontal X1 Soporta instalaciones en el p anel frontal
Conector de sonido frontal X1 Soporta funciones de sonido en el panel frontal
Conectores
en placa
Conector de salida S/PDIF X1 Soporta función de salida de sonido digital
