Motherboard Manual
44
RUSSIAN
СПЕЦ
CPU
(центральн
ый
процессор)
Гнездо FM1
Процессоры AMD A-Series / E2-Series
Архитектура AMD 64 разрешать обработка
данных на 32 и 64 бит
Набор
микросхем
AMD A55
Основная
память
Слоты DDR3 DIMM x 2
Максимальная ёмкость памяти 16ГБ
Каждый модуль DIMM поддерживает
512МБ /1ГБ/2ГБ/4ГБ/8ГБ DDR3
Модуль памяти с двухканальным режимом DDR3
Поддержка DDR3 800/1066/1333/1600/1866
Поддержка DDR3 2000 (OC)
Не поддерживает зарегистрированные модули
DIMM and ECC DIMM
Super I/O
ITE 8728
Обеспечивает наиболее используемые
действующие функциональные
возможности Super I/O.
Интерфейс с низким количеством выводов
Инициативы по охране окружающей среды,
Аппаратный монитор
Регул ятор скорости
Функция ITE "Smart Guardian"
(Интеллектуальная защита)
SATA II
Встроенное последовательное устройство
управления ATA
скорость передачи данных до 3 гигабит/с.
Соответствие спецификации SATA версия 2.0
Поддержка RAID 0,1,10
Локальная
сеть
RTL8111E / RTL8111F
Автоматическое согласование 10 / 100 / 1000
Мб/с
Частичная / полная дуплексная способность
Звуковой
кодек
VT1708B/ ALC662
Звуковая поддержка High- Def in ition
5.1канальный звуковой выход
Слот PCI Express Gen2 x16 x1
Слот PCI Express Gen2 x1 x2
Слоты
Слот PCI x3
Разъём SATA x6 Каждый разъём поддерживает 1 устройство SATA
Разъём на лицевой панели x1 Поддержка устройств на лицевой панели
Входной звуковой разъём x1
Поддержка звуко вых функций на лицевой
панели
Встроенны
й разъём
Разъём вывода для S/PDIF x1 Поддержка вывода цифровой звуковой фун кции
