distance of connectivity. The following is the summary table

of transmission setting, bandwidth and distance extensibility

tested for AWG 24 (0.5mm) twisted-pair without noise and

cross talk.

DIP-1 DIP-2 DIP-3 DIP-4

Mode Channel Rate Limit SNR

OFF CO Interleave 50/20 Mbps 9dB

ON(default) CPE Fast No Limit 6dB

● CO / CPE

▪ CO (Central Ofce) – the Master device mode, usually

the CO device will be located at the data center of ISP

or enterprise to link to the backbone.

▪ CPE (customer premises equipment) – the Slave device

mode, usually the CPE device will be located at branch

ofce, home or remote side as the long reach data re-

ceiver. The CPE can be connect to the PC, IP Camera or

Wireless Access Point and etc network devices.

● Fast and Interleave mode: (For CO Mode only)

▪ Fast mode guarantees a minimum end to end latency

less than 1 ms.

▪ Interleaved mode provides impulse noises protection for

any impulse noise with a duration less than 250 us. In-

terleaved mode has a maximum end to end latency of

10m sec.
