4. POWER INFORMATION
The power jack of VC-20x is with 2.5mm in the central post
and required +5VDC power input. It will conform to the
bundled AC-DC adapter and Planet’s Media Chassis. Should
you have the problem to make the power connection, please
contact your local sales representative.
Please keep the AC-DC adapter as spare parts when your
VC-20X is installed to a Media Chassis.
2.5mm
DC Receptacle 2.5mm
+5V for each slot
DC receptacle is 2.5mm wide that conforms to and
matches the VDSL2 Converter 2.5mm DC jack’s central
post. Do not install any improper unit, model of the
VDSL2 Converter
