1. Introduction
1.1 Checklist
Check the contents of your package for following parts:
● Ethernet over VDSL2 Converter
● Power Adapter
● RJ-11 Telephone line (VC-201 only)
● User’s Manual
If any of these pieces are missing or damaged, please
contact your dealer immediately, if possible, retain the
carton including the original packing material, and use them
against to repack the product in case there is a need to
return it to us for repair.
1.2 Introduction to Ethernet over VDSL2
Converter
PLANET’s state-of-the-art Ethernet-over-VDSL2 products
are based on two core networking technologies: Ethernet
and VDSL2 (Very-high-data-rate Digital Subscriber Line).
This technology offers the absolute fastest possible data
transmission speeds over existing copper telephone lines or
coaxial cables without the need for rewiring.
The VC-201/VC-202 Ethernet over VDSL2 converters has a
switching architecture with one RJ-45 10/100Mbps Ethernet
port and one symmetric Ethernet over VDSL port (symmetry
