8
means upstream and downstream rate are the same or
similar) – the VDSL port can be RJ-11 connectors or BNC
connector. The VC-201/VC-202 can be set to CO mode or
CPE mode via a DIP switch. When the VC-20X-CO is used
to connect to the other VC-20X-CPE as a standalone pair, up
to 100/55Mbps asymmetric data rate within 200m and up
to 30/6Mbps asymmetric data rate at 1km. This capability
is ideal for use as an Ethernet extender for your existing
Ethernet network.
PLANET’s VDSL2 Converter solution provides a much
cheaper replacement and smooth migration for existing
Long Reach Ethernet (LRE) networks.
The cable specications of the connection are listed as
following:
● 10BASE-T, Category 3, 4 or 5 UTP
● 100BASE-TX, Category 5 UTP
● Ethernet over VDSL, Twisted-pair telephone wires
● Ethernet over VDSL, Coaxial cable
The two drawings listed below are typical application for the
Ethernet over VDSL converter.
Note
Slave device (CPE) must connect to Master
device (CO) through the telephone wire. Slave
cannot connect to Slave and Master cannot
connect to Master. To define the VC-201 to CO
or CPE, please refer to section 2.2.1 for more
detail.
