MCP6P3/N68S3 BIOS Manual
22
4 Boot Menu
This menu allows you to setup the system boot options.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset Performance
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Scr een
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Specifies the
Boot Device
Priority sequenc e.
Boot Settings Conf iguration
> Hard Disk Drives
> Removable Drives
> CD/DVD Drives
Quick Boot [ Enabled]
AddOn ROM Display Mode [ Force BIOS]
Bootup Num-Lock [ On]
Interrupt 19 Captu re [ Disabled]
Ignore Memory Erro r Messages [ Disabled]
> Boot Device Prio rity
BOOT SUCCESS BEEP [ Enabled]
Exit
Boot Device Priority
Items in this sub-menu specify the boot device priority sequence from the available
devices. T he number of device items that appears on the screen depends on the
number of devices installed in the system.
Options: Removable / Hard Disk / CDROM / Legacy LAN / Disabled
Hard Disk Drives
T he BIOS will attempt to arrange the hard disk boot sequence automatically. You
can also ch ange the booting sequenc e. T he number of device items that app ears on
the screen depends on the number of devices installed in the system.
Options: P ri. Master / Pri. Slave / S ec. Master / Sec. S lave / USB HDD0 /
USB HDD1 / USB HDD2 / Bootable Add-in Cards
Removable Drives
T he BIOS will attempt to arrange the removable drive boot sequence automatically.
You can also change the booting sequence. The number of device items that
appears on the screen depends on the number of devices installed in the system.
Options: Floppy Disks / Zip100 / USB-FDD0 / USB-FDD1 / USB-ZIP0 /
USB-ZIP1 / LS120
