MCP6P3/N68S3 BIOS Manual
26
DCT Unganged Mode
This item controls the DRAM controller ganged (128bit*1) / unganged (64bit*2)
dual-chann el operation mode. If two DRAM modules with different size are
installed, using unganged mode can still make it run in dual-channel operation.
Options: Always (Default) / Auto
Power Down Enable
This item controls the DRAM power down function.
Options: Disabled (Default) / Enabled
Power Down Mode
This item allows you to set the DDR power down mode.
Options: Channel (Default) / Chip Select
Page Smashing
This item is S/W Control of Page Smashing Mechanism.
Options: Disabled (Default) / IC / DC / Both
Alternate VID
This item allows you to specify the alternate VID while in low power states..
Options: Auto (Default) / 0.800V ~ 1.550V (Interval: 0.025V)
SouthBridge MCP61 Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, Amer ican Megatre nds, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
SouthBridge MCP61 Chipset Conf iguration
OnChip and PCIe VGA selection[ Disable Onch ip VGA]
iGPU Frame Buffer Detect [ Auto]
AZALIA AUDIO [ Auto]
MAC LAN [ Auto]
PXE Support [ Disabled]
Primary Graphics Adapter [ PCI Express -> PCI]
OnChip VGA Frame Buffer Size [ 32MB]
MAC ID Informaiton :
Options
PCI Express -> PCI ->
IGP -> PCI -> PCI Expr
