MCP6P3/N68S3 BIOS Manual
5
nVidia RAID Setup
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Update
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
RAID Setup
SATA 1 Raid [Disabled]
nVidia RAID Function [Disabled]
SATA 2 Raid [Disabled]
SATA 3 Raid [Disabled]
SATA 4 Raid [Disabled]
Options
Dis
Enabled
abled
nVidia RAID Function
This item allows you to activate RAID function.
Options: Disabled (Default) / Enabled
SATA 1/2/3/4 Raid
Enable or disable RAID function of SATA devices.
Options: Disabled (Default) / Enabled
Primary IDE Master/Slave ; SATA 1/2/3/4 Device
BIOS SETUP UTILITY
Main
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Select the type
of device connected
to the system.
Primary IDE Master
LBA/Large Mode [Auto]
Block (Multi-Sector Transfer)[Auto]
PIO Mode [Auto]
DMA Mode [Auto]
S.M.A.R.T [Auto]
32Bit Data Transfer [Enabled]
Device :
Type [Auto]
