MCP6P3/N68S3 BIOS Manual
32
TR RD
Options: Auto (Default) / 4~7 CLK
tWTR
Options: Auto (Default) / 4~7 CLK
tRFC0 / tRFC1 / tRFC2 / tRFC3
Options: Auto (Default) / 90ns / 110ns / 160ns / 300ns / 350ns
AMD Overclocking Configuration
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
AMD Overclocking Configuration
Custom P-States [Disabled]
Core DID [Divided by 1]
NB VID [1.3250 V]
NB
Core FID [x13.0 2600MHz]
NB FID [1600 MHz]
DID [Divided by 1]
Performance
Tells BIOS whether to
use the setup options
below this to
configure the
P-States, or whether
to configure the
P-States automatically
Custom P-States
This item allows you to select the P-States controlling.
Options: Disabled (Default) / Enabled
Core FID
This item allows you to select the Ratio/Frequency of AM3 CPU.
Options: x8.0 1600MHz ~ x13 2600MHz
Core DID
This is the Core Divider.
Options: Divided by 1 (Default) / Divided by 2 / Divided by 4 / Divided by 8 /
Divided by 16
