MCP6P3/N68S3 BIOS Manual
28
Hyper Transport MCP61 Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 198 5-200x, American Megatre nds, Inc.
Select Screen
Select Item
Go to Sub Scr een
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Hyper Transport MC P61 Configuration
MCP61(SB)to K8(CPU )Freqency [800 MHZ]
MCP61(SB)to K8(CPU )LinkWidth [16 16 ]
MCP61(SB)to K8(CPU )Freq Auto [Enabled]
MCP61(SB) to K8( CPU)
frequency select ion
by CPU capabilit y
MCP61 (SB) to K8 (CPU) Freq Auto
This option allows you to auto control MCP61 (SB) to K8 (CPU) Frequency.
Options: Enabled (Default) / Disabled
MCP61 (SB) to K8 (CPU) Frequency
This option allows you to auto control MCP61 (SB) to K8 (CPU) Frequency.
Options: 800 MHz (Default) / 200 MHz / 400 MHz / 600 MHz / 1000 MHz
(Differed by CPU)
MCP61 (SB) to K8 (CPU) LinkWidth
This option allows you to auto control MCP61 (SB) to K8 (CPU) LinkWidth.
Options: 16↓16↑ (Default) / 8↓8↑ / 4↓4↑
