N68S3+ BIOS Manual
26
5 Chipset Menu
T his submenu allows you to configure the speci fic features of the chipset installed on
your system. T his chipset manage bus speeds and access to system memory
resources, such as DRAM. It also coordinates communications with the PCI bus.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Chipset Performance
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
Options for NBAdvanced Chipset Settings
WARNING: Setting wrong values in below sections
may cause system to malfunction.
> SouthBridge MCP68 Configuration
> Hyper Transport Configuration
> NorthBridge Configuration
Exit
NorthBridge Configuration
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
NorthBridge Chipset Configuration
Alternate VID [Auto]
Chipset
