N68S3+ BIOS Manual
31
PCIE/SATA Spread Spectrum
This item allows you to control PCIE/SATA Spread Spectrum function.
Options: Enabled (Default) / Disabled
CPU Voltage
This item allows you to select CPU Voltage Control.
Chipset Voltage
This item allows you to select Chipset Voltage Control.
FS B Voltage
This item allows you to select FSB Voltage Control.
Memory Voltage
This item allows you to select DDR Voltage Control.
DRAM Timing Configuration
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
DRAM Timing Configuration
Memory Clock Mode [Auto]
Memclock Value [Auto]
DRAM Timing Mode [Auto]
Memory CLK :
CAS Latency(Tcl) :
RAS/CAS Delay(Trcd) :
Row Precharge Time(Trp):
Min Active RAS(Tras) :
RAS/RAS Delay(Trrd) :
Row Cycle (Trc) :
Write Recover Time(Twr):
Select the DRAM
Frequency programming
method. If Auto,
the DRAM speed will
be based on SPDs.
If Limit, the DRAM spe
will not exceed the
specified value. If
Manual, the DRAM speed
specified will be
programmed regardless.
Performance
Memory Clock Mode
This item allows you to control the Memory Clock.
Options: Auto (Default) / Limit / Manual
