N68S3+ BIOS Manual
34
MemClk Tristate C3/ATLVID
This item enables or disables the MemClk Tristate function in C3 Mode.
Options: Disabled (Default) / Enabled
Memory Hole Remapping
This item allows you to enable or disable the remapping of the overlapped PCI
memory above the total physical memory. Only 64-bit OS supports this function.
Options: Enabled (Default) / Disabled
DCT Unganged Mode
This item controls the DRAM controller ganged (128bit*1) / unganged (64bit*2)
dual-channel operation mode. If two DRAM modules with different size are
installed, using unganged mode can still make it run in dual-channel operation.
Options: Auto (Default) /Always
Power Down Enable
This item controls the DRAM power down function.
Options: Enabled (Default) / Disabled
AMD Overclocking Configuration
BIOS SETUP UTILITY
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
AMD Overclocking Configuration
Custom P-States [Disabled]
Core FID [x14.5 2900MHz]
Core DID [Divided by 1]
NB FID [1600 MHz]
NB VID(Core VID) [1.4000 V]
NB DID [Divided by 1]
Performance
Tells BIOS whether to
use the setup options
below this to
configure the
P-States, or whether
to configure the
P-States automatically
