N68S3+ BIOS Manual
27
Alternate VID
This item allows you to specify the alternate VID while in low power states..
SouthBridge MCP68 Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
SouthBridge MCP61 Chipset Configuration
OnChip and PCIe VGA selection[Disable Onchip VGA]
iGPU Frame Buffer Detect [Auto]
AZALIA AUDIO [Auto]
MAC LAN [Auto]
Onboard Lan BootROM [Disabled]
Primary Graphics Adapter [PCI Express -> PCI]
OnChip VGA Frame Buffer Size [32MB]
MAC ID Informaiton :
Options
PCI Express -> PCI ->
IGP -> PCI -> PCI Expr
Primary Graphics Adapter
This item allows you to select Primary Graphics Adapter
Options: PCI Express → PCI -→ IGP (Default) / IGP → PCI → PCI Express
OnChip and PCIe VGA selection
This item allows you to select OnChip or PCIe VGA to display
Options: Disable Onchip VGA if have PCIe VGA (Default) / Both exist and
OnChip VGA by frame bu ffer select
iGPU Frame Buffer Detect
This item allows you to control the iGPU frame buffer.
Options: Auto (Default) / Disabled
iGPU Frame Buffer Size
This item allows you to choose the frame buffer size o f on-chip VGA.
Options: 32MB (Default) / 16MB / 64MB / 128MB / 256MB / Disabled
