Biostar N68S3B Версия 6.x [10/47] A memory modules

Motherboard Manual

2.3 INSTALLING SYSTEM MEMORY

A. Memory Modules

D3_A1DR

D3_DR B1

1. Unlock a DIMM slot by pressing the retaining clips outward. Align a

DIMM on the slot so that the notch on the DIMM matches the break

on the Slot.

2. Insert the DIMM vertically and firmly into the slot until the retaining

chip snap back in place and the DIMM is properly seated.
