Motherboard Manual
30
FRENCH
SPEC
UC
Socket AM3
Processeurs AMD Phenom II/ Athlon II
(Watt maximum : 95W)
L'architecture AMD 64 permet le calcul 32 et 64 bits
Prend en charge Hyper Transport 2.0
Bus frontal
Prend en charge Hyper Transport 2.0
jusqu'à une bande passante de 2.0 GT/s
Chipset GeForce 7025/nForce 630a
Super E/S
ITE 8728
Fournit la fonctionnalité de Super E/S
patrimoniales la plus utilisée.
Interface à faib le co mpte de broches
Initiatives de contrôle environnementales,
Mon iteur d e mat ériel
Fonction "Gardien intelligent" de l'ITE
Mémoire
principale
Fentes DDR3 DIMM x 2
Capacité mémo ire max imale de 8 Go
Chaque DIMM prend en charge des DDR3
de 512Mo/1Go /2Go/4Go
Modu le d e mémo ire DDR3 à mod e à double vo ie
Prend en charge la DDR3 800 / 1066 / 1333
Les DIMM à registres et DIMM avec code correcteurs
d'erreurs ne sont pas prises en charge
Graphiques Integré dans la chipset GeForce 7025 Mémoire vidéo partagée maximale de 512 Mo
IDE Contrôleur IDE intégré
Mode principale de Bus Ultra DMA 33 / 66 / 100 / 133
Prend en charge le mode PIO 0~4,
SATA
Contrôleur Serial ATA
int égr é
Taux de transfert jusqu'à 3 Go/s.
Conforme à la s pécif icat ion SATA Vers ion 2.0
LAN Realtek RTL 8201CL
10 / 100 Mb/s négociation automatique
Half / Full duplex capability
Prise en
charge
audio HD
VT1708B
Sortie audio à 5.1 voies
Prise en charge de l'audio haut e définition
Fente PCI Express x16 x1
Fentes
Fente PCI x1
Connecteur IDE x1
Chaque connecteur prend en charge 2 périphériques
IDE
Connecteur SATA x2
Chaque connecteur prend en charge 1 périphérique
SATA
Connecteur du panneau avant x1 Prend en charge les équipements du panneau avant
Connecteur
embarqué
Connecteur Audio du panneau avant x1 Prend en charge la fonction audio du panneau avant
