Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
JKBMS
JKB_PWR
JATXPWR4
JVGA
JUSB1
JUSBLAN1
JAUDIO1
JUSBPWR1
JCFAN
BAT1
LAN
JAU DIO F
Codec
PCI1
JPRNT
SATA2 SATA1
JSFAN
JPA NEL 1
BIOS
Super I/O
JCMOS1
JUSB2 JUSB3
JUSB PWR2
IDE
JATXPWR1
DDR3_B1
DDR3_A1
PEX16_1
GeForce
7025/
nForce
630a
Socket AM3
Note: represents the 1■
st
pin.
