Biostar N68S3B Версия 6.x [7/47] Chapter 2 hardware installation

N68S3B

CHAPTER 2: HARDWARE INSTALLATION

2.1 I

NSTALLING CENTRAL PROCESSING UNIT (CPU)

Step 1: Pull the lever toward direction A from the socket and then raise the

lever up to a 90-degree angle.

Step 2: Look for the white triangle on socket, and the gold triangle on

CPU should point towards this white triangle. The CPU will fit only

in the correct orientation.
