A770L3
33
SPEC
Connecteur de disquette x1
Chaque connector prend en charge 1 lecteur de
disquette
Connecteur de Port d'imprimante x1
Chaque connector prend en charge 1 Port
d'imprimante
Connecteur IDE x1
Chaque connecteur prend en charge 2 périphériques
IDE
Connecteur SATA x4
Chaque connecteur prend en charg e 1 périphérique
SATA
Connecteur du panneau avant x1 Prend en charge les équipements du panneau avant
Connecteur Audio du panneau avant x1 Prend en ch arge la fonct ion aud io du panneau avant
Connecteur de sortie S/PDIF x1 Prend en charge la fonction de sortie audio numérique
Embase de ventilateur UC x1
Alimentation électrique du ventilateur UC (avec
fonction de ventilateur intelligent)
Embase de ventilateur système x2 Alimentation électrique du ventilateur système
Embase d'effacement CMOS x1
Connecteur USB x2
Chaque connecteur prend en charge 2 ports USB de
panneau avant
Connecteur d' alimentation x1
(24 broches)
Connecteur
embarqué
Connecteur d' alimentation x1
(4 broches)
E/S du
panneau
arrière
Clavier PS/2 x1
Souris PS/2 x1
Port série x1
Port LAN x1
Port USB x4
Fiche audio x3
Dimensions
de la carte
182 mm (l) X 305 mm (H) ATX
Support SE
Windows XP / Vista / 7
Biostar se réserve le droit d'ajouter ou de supprimer
le support de SE avec ou sans préavis.
