Motherboard Manual
4
1.5 MOTHERBOARD LAYOUT
KBMS1
ATXPWR2
USB1
RJ45USB1
AU DIO1
COM1
JUSBV1
LAN
Super I/O
Codec
F_AUDIO1
JSPDIFOUT1
J_PRINT1
FDD1
PCI3
PCI2
PCI1
PEX16_1
PEX1_1
AMD
770
AT XP W R 1
IDE1
BAT
F_USB1 F_USB2
PAN EL1
JUSBV2
AMD
SB710
BIOS
SYS_FAN1
JCMOS1
CPU_FAN1
DDR3_A1
DDR3_B1
SATA1
SATA2
SATA3
SATA4
Socket AM3
Note: represents the 1■
st
pin.
