Motherboard Manual
36
SPANISH
Especificación
CPU
Conector AM3
Procesadores AMD Sempron / Athlon II /
Pheno m II (Vat io máximo: 95W)
La arquitectura AMD 64 permite el procesado de 32 y
64 bits
Soporta las tecnologías Hyper Transport 3.0
FSB
Admite HyperTransport 3.0 con un ancho
de banda de hasta 5.2 GT/s
Conjunto de
chips
AMD 770
AMD SB710
Súper E/S
ITE 8721
Le ofrece las funcionalidades heredadas de
uso más común Súper E /S.
Interfaz de cuenta Low Pin
In iciat ivas de control d e entorno,
Monitor hardware
Controlador de velocidad de ventilador
Función "Guardia inteligente" de ITE
Memoria
principal
Ranuras DIMM DDR3 x 2
Capacidad máxima de memoria de 8GB
Cada DIMM admite DDR de
512MB/1GB/2GB/4GB
Módulo de memoria DDR3 de canal Doble
Admite DDR3 de 800 / 1066 / 1333
Admite DDR3 de 1600 (OC)
No admite DIMM registrados o DIMM compatibles con
ECC
IDE
Controlador IDE integrado
Modo bus maestro Ultra DMA 33 / 66 / 100 / 133
Soporte los Modos PIO 0~4,
SATA II
Controlador Serial ATA integrado
Tasas de transferencia de hasta 3 Gb/s.
Compat ib le con la vers ión SATA 2.0.
Admite RAID 0,1,10
Red Local
Realtek RTL 8102EL
Negociación de 10 / 100 Mb/s
Funciones Half / Full dúplex
Códecs de
sonido
ALC662 / VT1708B
Salida de sonido de 5.1 canales
Soporte de sonido de Alta Definición
Ranura PCI X3
Ranura PCI Express Gen2 x16 X1
Ranuras
Ranura PCI express Gen2 x1 X1
