Motherboard Manual
40
POLISH
SPEC
Procesor
Socket AM3
AMD Sempron / Athlon II / Phenom II Procesory
(Maksymalny Watt: 95W)
Architektura AMD 64 umożliwia przetwarzanie
32 i 64 bitowe
Obsługa Hyper Transport 3.0
FSB
Obsługa HyperTransport 3.0 o szerokości pasma
do 5.2 GT/s
Chipset
AMD 770
AMD SB710
Pamięć
główna
Gniazda DDR3 DIMM x 2
Maks. wielkość pamięci 8GB
Każde gniazdo DIMM obsługuje moduły
512MB/1GB/2GB/4GB DDR3
Moduł pamięci DDR3 z trybem podwójnego
kanału
Obsługa DDR3 800 / 1066 / 1333
Obsługa DDR3 1600 (OC)
Brak obsługi Registered DIMM oraz ECC D IMM
Super I/O
ITE 8721
Zapewnia najbardziej powszechne funkcje Super
I/O.
Interfejs Low Pin Count
Funkcje kontroli warunków pracy,
Mon itor H/W
Kontroler prędkości wentylatora
Funkcja ITE "Smart Guard ian"
IDE
Zintegrowany kontroler IDE
Ultra DMA 33 / 66 / 100 / 133 Tryb Bus Master
obsługa PIO tryb 0~4,
SATA II
Zintegrowany kontroler Serial ATA
Transfer danych do 3 Gb/s.
Zgodność ze specyfikacją SATA w wersj i 2.0.
Obsługa RAID 0,1,10
LAN
Realtek RTL 8102EL
10 / 100 Mb/s z automatyczną negocjacją
szybkości
Działanie w trybie połowicznego/pełnego
dupleksu
Kodek
dźwiękowy
ALC662 / VT1708B
5.1 kanałowe wyjście audio
Obsługa High-Defin ition Audio
Gniazdo PCI x3
Gniazdo PCI Express Gen2 x16 x1
Gniazda
Gniazdo PCI Express Gen2 x1 x1
