A740G3L BIOS Manual
24
AMD 740 Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Go to Sub Screen
General Help
Save and Exit
Exit
Enter
F1
F10
ESC
AMD 740 Configuration
> Internal Graphics Configuration
> PCI Express Configuration
AMD 740 HD Audio [Disabled]
Internal Graphics Conf
Internal Graphics Configuration
BIOS SETUP UTILITY
Chipset
vxx.xx (C)Copyright 1985-200x, American Megatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
Internal Graphics
UMA Frame Buffer Size [Auto]
Graphics Clock Mode [Sync]
Multifunction [Disabled]
Primary Video Controller [PCIE/IGFX/PCI]
Internal Graphics Mode [UMA]
Current UMA Size [128MB]
Surround View [Disabled]
Options
Disable
UMA
Internal Graphics Mode
This item allows you to select the memory mode used for internal graphics device.
Options: UMA (Default) / Disable
