A740G3L BIOS Manual

Voltage Configuration

BIOS SETUP UTILITY

Select Screen

Select Item

Change Option

General Help

Save and Exit

Exit

F10

ESC

Voltage Configuration

CPU Over Voltage [StartUp]

Memory

Chipset/HT Over Voltage [1.25V]

Over Voltage [1.60V]

Performance

Change CPU voltage

value.

CPU Over Voltage

This item allows you to change CPU voltage value.

Memory Over Voltage

This item allows you to select DDR Over Voltage Control.

Chipset/HT Over Voltage

This item allows you to select Chipset/HT Over Voltage Control.
