A740G3L BIOS Manual
36
Memory Hole Remapping
This item allows you to enable or disable the remapping of the overlapped PCI
memory above the total physical memory. Only 64-bit OS supports this function.
Options: Enabled (Default) / Disabled
DCT Unganged Mode
This item controls the DRAM controller ganged (128bit*1) / unganged (64bit*2)
dual-channel operation mode. If two DRAM modules with different size are
installed, using unganged mode can still make it run in dual-channel operation.
Options: Always (Default) / Auto
Power Down Enable
This item controls the DRAM power down function.
Options: Enabled (Default) / Disabled
Page Smashing
This item is S/W Control of Page Smashing Mechanism.
Options: Disabled (Default) / IC / DC / Both
ECC Configuration
BIOS SETUP U TILITY
vxx.xx (C)Copyright 1985-200x, American Me gatrends, Inc.
Select Screen
Select Item
Change Option
General Help
Save and Exit
Exit
+-
F1
F10
ESC
ECC Configuration
ECC Mode [Dis abled]
DRAM ECC Enable [Dis abled]
DRAM SCRUB REDIRECT [Dis abled]
4-Bit ECC Mode [Dis abled]
DRAM BG Scrub [Dis abled]
Data Cache BG Scrub [Dis abled]
L2 Cache BG Scrub [Dis abled]
L3 Cache BG Scrub [Dis abled]
Set the level of ECC
protection. Note: The
Super ECC mode
dynamically sets the
DRAM scrub rate so
all of memory is
scrubbed in 8 hours.
Performance
